Technical Specifications
Frequency Coverage: 5 – 2500 MHz
Span Width: 0 – 1250 MHz
Resolution Bandwidth: 10kHz, 100kHz, 300kHz, 1MHz
RF Sensitivity: Greater than – 85 dBm Typical
Reference Levels: Selectable – 10 dBm to – 50 dBm in 20 dB steps
Scale: 5 dB/Div
Dynamic Range: 40 dB on Application Window
Amplitude Accuracy: +/- 1 dB typical
Frequency Accuracy: +/- 1kHz typical
Inputs: Dual Inputs (Switched)
Input Connector: “N” Type others available upon request
Size: 19” W X 1.75” H X 18” D
Power Requirements: 85 to 265VAC, 50/60Hz
Display: Avcom Custom GUI based on National Instruments Labview
Platform.
