Features
● SDI Video Input
40 x SDI/HD-SDI, 3Gb/s SDI and ASI
● SDI Video Output
40 x SDI/HD-SDI, 3Gb/s SDI and ASI with SDI re-clocking
● Multi Rate Support
Auto detection of SD, HD or 3 Gb/s SDI. Simultaneous routing of 2K, HD,
SD video and DVB-ASI
● Device Control
None
● Router Control
Use either RJ45 Ethernet or USB 2.0 high speed interface or Smart Control
shared over IP network
● Router Configuration
Use either RJ45 Ethernet or USB 2.0 high speed interface shared over IP
network
● RS-422 Router Control
1 x input for controlling router crosspoint switching
● Updates
USB 2.0 high speed (480Mb/s) interface
● Re-clocking
On all SDI outputs, auto switching between standard definition, high
definition or 3 Gb/s SDI video
● Reference Input
Blackburst and TriSync for SD, HD and 2K
