Technical Specifications
Frequency Coverage: 950 – 2150 MHz
Span Width: 0 – 1200 MHz
Resolution Bandwidth: 10KHz, 100KHz, 300KHz, 1MHz
RF Sensitivity: Greater than – 85 dBm Typical
Reference Levels: Selectable – 10 dBm to – 50 dBm in 20 dB steps
Scale: 5 dB/Div
Dynamic Range: 40 dB on Application Window
Amplitude Accuracy: +/- 1 dB typical
Frequency Accuracy: +/- 1KHz typical
Input Connector: “N” Type others available upon request
Power Requirements: 85-240 V.A.C. Or 12 V.D.C.
Display: Avcom Custom GUI based on National Instruments Labview
Platform.
