Açıklama
Display Spec.
Size 9″
Resolution 960 X 540 (16 : 9)
Pixel Pitch 0.207mm
Color Depth 16.7M
Viewing
Angle
170°(H) / 170°(V)
Luminance 400cd/m2
Contrast
Ratio
1000:1
Display Area 199(H) x 112(V) mm
Input
3 X BNC Analog Input (Component)
2 X BNC 3G-SDI A/B Channel Input
1 X DVI DVI Input
Output
1 X BNC HD-SDI Output
Input Signal
SDI Input Signal Formats
Audio
Audio In Embedded Audio/Analog Stereo (Phone Jack)
Audio Out Analog Stereo (Phone Jack), Internal Speaker(Stereo)
FPGA Functions
1:1 Pixel Mapping Modes for SD/HD, 3G-SDI Level A/B, Audio Level Meter
Display, Blue Only, Focus Assist, H/V Delay, H/V Flip, Luma(Y’) Zone Check,
Marker, Mono, Range Error, Time Code Display, UMD, User Aspect,
Waveform/Vector
Closed Caption
CC-608 ANC, CC-608 LINE 21, CC-708
Calibration
Other Functions
REMOTE TVLogic’s specification
USB
Ethernet
Options
Camera Mount, Ball Head, Carrying Case, External Acrylic Filter, Rack Mount
Kit(Double), Rack Mount Kit(Single), Sun Hood, V-Mount
